視質量為生命,奉用戶為上帝,并一貫遵循對每一道工序負責,對每一臺產品負責,對每一位用戶負責的質量方針,竭誠為用戶服務。
| 掃路機參數 Road sweeper parameters | |||||
| 滾刷直徑 Brush diameter(mm) | 660 | ||||
| 邊刷 Side brushes | 左右邊刷 Brush left and right | ||||
| 滾刷材質 Roller brush material | 加強鋼絲尼龍過混合 Reinforced steel wire nylon over mixing | ||||
| 邊刷蕞大直徑 Maximum diameter of side brushes(mm) | 600 | ||||
| 邊刷材質 Edge brush material | 鋼片+粗細尼龍混編 Steel sheet + thick and thin nylon mixing | ||||
| 裝置尺寸 Dimensions of the device(mm) | 2100*2400*1000 | ||||
| 滾刷蕞高轉速 The maximum speed of the roller brush(r/min) | 260 | ||||
| 蕞大清掃寬度 Maximum sweeping width(mm) | 2200-2400 | ||||
| 垃圾箱清掃寬度 Dustbin sweeping width(mm) | 1600-1800 | ||||
| 工作裝置操作方式 The operation mode of the working device | 機械彈手柄操作 Mechanical elastic handle operation | ||||
| 散熱系統 Cooling system | 獨立雙油散 Independent double oil dispersion | ||||
| 液壓系統H ydraulics | 雙泵雙閥 Twin pumps and double valves | ||||
| 雙水箱總?cè)莘e Total volume of double water tanks(L) | 1500 | ||||
| 垃圾箱容積 Dustbin volume(m3) | 1 | ||||
| 灑水系統 Sprinkler system | 電動分控式Electric sub-control | ||||
| 清掃能力 Sweeping capacity(m3/h) | 25000 | ||||
| 升降方式Lifting mode | 動臂升降 Boom lifting | ||||
