| 整機參數 Parameters of the whole machine | 整機參數 Parameters of the whole machine | ||||||||
| 項目project | 參數parameter | 項目project | 參數parameter | ||||||
| zui小轉彎半徑 Minimum turning radius(mm) | 4800 | 車身長度 Body length(mm) | 5400 | ||||||
| 理論爬坡角度 Theoretical climbing angle(°) | 15 | 車身寬度 Body width(mm) | 1850 | ||||||
| zui大行駛速度 Maximum travel speed(KM) | 32 | 車身高度 Vehicle height(mm) | 2750 | ||||||
| zui小行駛速度 Minimum travel speed(KM) | 8 | zui小離地間隙 Minimum ground clearance(mm) | 255 | ||||||
| zui大卸載高度 Maximum unloading height(mm) | 3200 | 輪距tread(mm) | 1500 | ||||||
| 空載提升時間 No-load lifting time(s) | ≤4.8 | 額定裝載質量 Rated loading mass(kg) | 1600 | ||||||
| 空載下降時間 No-load drop time(s) | ≤3.1 | 整機重量 The weight of the whole machine(kg) | 4600 | ||||||
| 空載卸料時間No-load unloading time(s) | ≤1.2 | 鏟斗長.深.高 Bucket length. Deep. high(mm) | 1800*450*860 | ||||||
| 三項和 Three and(s) | ≤9.1 | 斗容Dourong(m3) | 0.7 | ||||||
| 軸距 wheelbase(mm) | 2250 | zui大崛起力 Maximum Rising Force(KN) | 22 | ||||||
| 卸料距離 Discharge distance(mm) | 800 | zui大牽引力 Maximum traction(KN) | 28 | ||||||
| 卸料角度 Discharge angle(°) | 35.1 | 聯合工況牽引力 Combined service traction(KN) | 26 | ||||||
| 發動機參數 Engine parameters | 傳動系統參數 Drivetrain parameters | ||||||||
| 項目 project | 參數 parameter | 項目 project | 參數 parameter | ||||||
| 廠家 factory | 云內國二 | 型式 version | 265雙高低速 | ||||||
| 額定功率 Rated power(kw) | 55KW | 變速檔位 Shifting gears | 前四后四 the last four | ||||||
| 額定轉速(r/min) | 2400 | 制動形式 Brake form | 氣剎 Air brakes | ||||||
| 氣缸數Rated speed | 4 | 車橋Axles | 小輪邊 Small wheel side | ||||||
| 輪胎型號 Tire model | 23.5-70/16 | ||||||||
| 前輪氣壓 Front wheel pressure(Map) | 0.33 | ||||||||
| 后輪氣壓 Rear wheel pressure(Map) | 0.3 | ||||||||
| 轉向系統 Steering system | 加油容量 Refueling capacity | ||||||||
| 項目 project | 參數 parameter | 項目 project | 參數 parameter | ||||||
| 型式version | Fully hydraulic steering | 燃油理論溶劑 Fuel theory solvents(L) | 65.5 | ||||||
| 轉向角度 Steering angle(°) | 32.5 | 液壓油理論容積Theoretical volume of hydraulic fluid (L) | 65.5 | ||||||
| 系統工作壓力 System operating pressure (Mpa) | 16 | 橋 單條 Bridge single(L) | 14 | ||||||
| 發動機機油 Engine oil(L) | 6.5 | ||||||||
| 變速箱齒輪油 Transmission gear oil(L) | 24 | ||||||||
| 制動系統 Braking system(L) | 3 | ||||||||
